LEION HEY

See and Understand Everything That You Hear, Anywhere, Anytime.

LEION HEY Augmented Glasses were issued as “The Top 10 Global Science and Technology Innovation Awards” by UNESCO (United Nations Educational, Scientific and Cultural Organization) Netexplo Innovation Forum on April 13th, 2022.

LEION HEY is an augmented reality eyewear designed for voice interaction and translation. It is featured with binocular translucent optics, fast and accurate voice engine, and ultra lightweight all-in-one body. AR captions and other contents are displayed right in front of your eyes as you need.

TRANSLATION

CHATGPT

HEARING AID

AUGMENTED REALITY

TRANSLATION CHATGPT HEARING AID AUGMENTED REALITY

Immersive Conversations, Infinite Functionality

Speak, translate, connect, empower

Binocular Optical Waveguide Displays

Crystal clear lenses, both display vivid, bright and accurate AR images

Lightweight

Comfortable to wear

Multilingual

Recognition and translation

Professional Audio System

Dual microphone arrays with neural network noise reduction algorithm

Qualcomm Snapdragon Wear 4100 Platform

Optimized for extremely low power consumption

Untethered

Everything in a slim body

TRANSLATION

CHATGPT

HEARING AID

AND MORE

Now Experiencing Them In AR

Personal Assistance

Business Negotiations / Meetings

Study Aboard

Watch Movies

Go Pubbing

International Travels

Transnational Family Communications

Hearing Aid

Talk with ChatGPT to get suggestions, or translate a foreign language to your native ones, communications and entertainments have never been easier with LEION HEY AR Glasses.

Crystal Clear Reality, Transcended with Pristine AR

AR is more than just making large displays

85%

Transmission

1500nits

Maximum Brightness

0.05°

Binocular Fusion Accuracy

23°

Golden FOV

RGB

Full Color Displays

<0.5%

Light Leakage

The combination of translucent optics and bright displays makes LEION HEY easy and safe to use [1] - either under daylight or in the evening. By applying appropriate display area for reading [2], in addition with hundreds rounds of human eye simulation cameras calibration in the manufacturing process, fatigues caused by strabismus and inappropriate eye movements are eliminated. There is no visible light leakage from the front as well [3], makes the device your private displays.

World’s Lightest

[4]

The Combination of Aerospace Grade Materials

Sabic ULTEM™ Frame And Temples

The frame and temple of LEION HEY is made out of Sabic ULTEM™ (PEI) resin, which is significantly lighter than carbon fiber.

Titanium Screws And Nose Pad Arms

Screws and nose pad arms are made out of titanium, these made the device lightweight and reliable.

0.3mm Aerogel Heat Insulation Inserts

Several feather weight aerogel inserts are installed in LEION HEY, to insulate heat generated from processor.

0.02mm Graphene Heat Dispatch Film

Graphene film is used in LEION HEY for heat dispatch feature, its weight is almost negligible.

It Can Really Hear

Professional Array Microphones on An Eyewear

LEION HEY comes with dual microphones array design, its frequency response covers full human hearing range [5]. Both whispers and long-range speeches can be captured for translations or interactions.

-36dBFS

Sensitivity

132db

Dynamic Range

20~20KHz

Frequency Range

Active Neural Network Noise Reduction

LEION HEY performs over 85% of voice recognition accuracy in the environment with 70db noise, from 5 meters away. [6]

Intelligent Audio Beam Forming

Audios from the front are captured with higher priority [7], this strategy is optimized for voice recognition in noise environments.

From Words to Worlds

It Has Got You Covered

Faithfulness, Expressiveness And Elegance Translation

LEION HEY is embedded with Automatic Speech Recognition and Translation Engine, based on advance machine learning technology, voice recognition experience are instant and intuitive.

500ms

Ultra-low Latency

89

Languages Recognition And Translation [8]

Intelligent

Sentence Segmentation And Speech Correction

Records

Conversation History Data Can Be Storaged

Capable,

Without Cable

World’s First All-in-one Binocular AR Glasses

LEION HEY works without smartphones. It runs a customized version of Android 11 Go Edition operating system, and optimized specifically for power efficiency. The USB Type-C port supports fast charge, battery can be charged from 0 to 80% within 30 minutes.

Android Go

Fluid and efficient

90 mins translation [9]

Battery

Wireless

WLAN and Bluetooth

One-touch to start

Button Control

Powerful,

Yet Efficient

Qualcomm Snapdragon Wear 4100 Platform

Designed for next generation smart wearables, with dedicated Audio DSP

12nm

Process

1.7GHz

A53 Quad Core Processor

<1.0W

Power Consumption

It Fits You

In So Many Ways

  • Make them your own displays

    Setup font size, text formatting and background color according to your reading preference.

  • Get notified

    By adding keywords in the phone App, LEION HEY will flicker the displays once keywords are detected.

  • Filter you own voices

    Clutters are eliminated by filter your own voice input when translating the conversation.

  • See your improvements

    Your weekly report is updated every Monday, which gives you communication performance evaluation.

  • Comfortable for different people

    Adjustable temple inserts, nose pads with air chamber and titanium arms, make LEION HEY compatible with different head dimensions.

  • Various of accessory lenses

    Magnetic sunglasses filter and prescription lenses frame (for myopia, hyperopia, presbyopia or astigmatism) are included in the package [10].

  1. The displays have 85% of light transmission, which meets requirements including ANSI Z80.3-2001, EN 1836:2005, and QBT2457-2003.

  2. The display field of view for each eye is 23° diagonal, 20° horizontal. According to LLVISION’s lab test, with this specification, no significant eye movement is required for text reading.

  3. The light leakage (measured from the front surface of both optical waveguide lenses) is less than 0.5% of current brightness, which can not be sensed by human naked eyes.

  4. LEION HEY weights 79 grams (default weight, without sunglasses filter, prescription lenses and other accessories), which is the lightest in its category (binocular augmented reality glasses, optical waveguide displays, untethered)

  5. For typical human hearing range, the frequency response is 0 to 120dB, 20 to 20KHz, LEION HEY’s microphone array covers this range completely.

  6. The voice recognition accuracy various according to the distance between audio source and LEION HEY. Our test result shows over 95% of accuracy from 1 meter away, 90% from 3 meters away, and 85% from 5 meters away.

  7. Audios come from 60° range in the front are captured with higher priority, while audios come from other directions are volume down

  8. LEION HEY recognize and translate up to 91 languages from different countries and regions, including: Afrikaans (South Africa), Albanian, Amharic, Arabic, Armenian, Assamese, Azerbaijani, Bangla, Bosnian (Latin), Bulgarian, Cantonese (Traditional), Catalan, Chinese (Literary), Chinese (Simplified), Chinese (Traditional), Croatian, Czech, Danish, Dari, Dutch, English, Estonian, Fijian, Filipino, Finnish, French, French (Canada), German, Greek, Gujarati, Haitian Creole, Hebrew, Hindi, Hmong White, Hungarian, Icelandic, Indonesian, Inuktitut, Irish, Italian, Japanese, Kannada, Kazakh, Khmer, Klingon, Klingon (pIqaD), Korean, Kurdish (Central), Kurdish (Northern), Lao, Latvian, Lithuanian, Malagasy, Malay, Malayalam, Maltese, Maori, Marathi, Myanmar, Nepali, Norwegian, Odia, Pashto, Persian, Polish, Portuguese (Brazil), Portuguese (Portugal), Punjabi, Queretaro Otomi, Romanian, Russian, Samoan, Serbian (Cyrillic), Serbian (Latin), Slovak, Slovenian, Spanish, Swahili, Swedish, Tahitian, Tamil, Telugu, Thai, Tigrinya, Tongan, Turkish, Ukrainian, Urdu, Vietnamese, Welsh, Yucatec Maya.

  9. The built-in battery capacity is 400 mAh, it supports up to 90 minutes of battery life for typical voice translation (with 10 minutes stand by after each 30 minutes translations), in the condition of: 50% display brightness, good WLAN connection, 25°C environmental temperature.

  10. The prescription lenses included in the package are installed with plain glasses by default. Bring them to an eyewear store, If you need to customize your own myopia, hyperopia, presbyopia or astigmatism lenses. This prescription lenses frame is compatible with conventional eyewear manufacture standards.
